About HDMI
■ Compatible functions
HDMI (High Definition Multimedia Interface) is a digital
interface standard for connecting TVs, projectors, Blu-
ray Disc/DVD players, set-top boxes, and other video
components. Until now, several separate video and audio
cables have been required to connect AV components.
With HDMI, a single cable can carry control signals, digital
video and digital audio (2 ch PCM, multichannel digital
audio, and multichannel PCM).
HDMI CEC functionality:
By connecting devices and HDMI cables that comply with
the CEC (Consumer Electronics Control) specification of
the HDMI standard, a variety of linked operation become
possible between devices. You can enjoy features such as
linking input switching with the input selector and players,
control volume using the remote controller of the TV, and
automatically switching this unit to standby when the TV is
turned off.
The unit is designed to link with products that comply with
the CEC standard, and that linked operation is not always
guaranteed with all CEC devices. For linked functions
to work properly, do not connect more CEC-compliant
components than the quantities specified below, to the
HDMI jack.
•
Blu-ray Disc/DVD players: up to 3 units.
•
Blu-ray Disc/DVD recorders: up to 3 units.
•
Cable TV tuner, terrestrial digital tuner, and satellite
broadcasting tuner: up to 4 units.
Operation has been confirmed on the following devices:
(As of February 2016)
Toshiba brand televisions; Sharp brand televisions; Onkyo
and Integra brand RIHD-compatible players; Toshiba brand
players and recorders; Sharp brand players and recorders
(when used with a Sharp brand television)
ARC（Audio Return Channel）:
By connection a TV that supports ARC with a single HDMI
cable, you can not only output the audio and video from
this unit to the TV, but also input the audio from the TV to
this unit.
HDMI Standby Through:
Even if this unit is in standby, the input signals from AV
components are transmitted to the TV.
Deep Color:
By connecting devices supporting Deep Color, video
signals input from the devices can be reproduced on the
TV with even more colors.
x�v�Color™:
This technology realizes even more realistic colors by
broadening the color gamut.
3D:
You can transmit 3D video signals from AV components to
the TV.
4K:
This unit supports 4K (3840×2160p) and 4K SMPTE
(4096×2160p) video signals.
LipSync:
This setting automatically corrects any desynchronization
between the video and audio signals based on data from
the HDMI LipSync compatible TV.
Copyright Protection:
The unit supports Revision 1.4 and Revision 2.2 (HDMI
OUT MAIN/SUB and HDMI IN1 to 5 only) of the HDCP
(High-bandwidth Digital Content Protection), a copy-
protection system for digital video signals. Other devices
connected to the unit must also support HDCP.
■ Supported Audio Formats
2 ch linear PCM:
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz,
192 kHz, 16/20/24 bit
Multi-channel linear PCM:
Maximum 7.1 channels, 32 kHz, 44.1 kHz, 48 kHz,
88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 16/20/24 bit
Bitstream:
Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby
TrueHD, DTS, DTS:X, DTS-HD High Resolution Audio,
DTS-HD Master Audio
DSD:
Supported sampling rates: 2.8 MHz
Your Blu-ray Disc/DVD player must also support HDMI
output of the above audio formats.
■ Supported resolutions
HDMI IN1 to IN5:
•
Copyright protection technology: HDCP1.4/HDCP2.2
•
Color space (Color Depth):
–
720×480i 60Hz, 720×576i 50Hz, 720×480p
60Hz, 720×576p 50Hz, 1920×1080i 50/60Hz,
1280×720p 24/25/30/50/60Hz, 1680×720p
24/25/30/50/60Hz, 1920×1080p 24/25/30/50/60Hz,
2560×1080p 24/25/30/50/60Hz, 4K (3840×2160p)
24/25/30Hz, 4K SMPTE (4096×2160p) 24/25/30Hz :
RGB/YCbCr4:4:4 (8/10/12 bit), YCbCr4:2:2 (12 bit)
–
4K (3840×2160p) 50/60Hz, 4K SMPTE (4096
×2160p) 50/60Hz : RGB/YCbCr4:4:4 (8 bit),
YCbCr4:2:2 (12 bit), YCbCr4:2:0 (8/10/12 bit)
HDMI IN6 to IN7, Front:
•
Copyright protection technology: HDCP1.4
•
Color space (Color Depth):
–
720×480i 60Hz, 720×576i 50Hz, 720×480p
60Hz, 720×576p 50Hz, 1920×1080i 50/60Hz,
1280×720p 24/25/30/50/60Hz, 1680×720p
24/25/30/50/60Hz, 1920×1080p 24/25/30/50/60Hz,
2560×1080p 24/25/30/50/60Hz : RGB/YCbCr4:4:4
(8/10/12 bit), YCbCr4:2:2 (12 bit)
–
4K (3840×2160p) 24/25/30Hz, 4K SMPTE (4096
×2160p) 24/25/30Hz : RGB/YCbCr4:4:4 (8 bit),
YCbCr4:2:2 (12 bit)
–
4K (3840×2160p) 50/60Hz, 4K SMPTE (4096×
2160p) 50/60Hz : YCbCr4:2:0 (8 bit)
