35
> Network Functions > Specifications > Advanced Setup > Listening Modes
Troubleshooting Supplementary Information, etc�|
> Basic Manual
Selecting Listening Modes
Select the optimum listening mode for movies, TV, music,
and games by repeatedly pressing the MOVIE/TV, MUSIC,
and GAME buttons.
1. During play, press one of the following three buttons on
the remote controller.
2. Press the selected button repeatedly to switch the
modes displayed on the display of the unit.
For details on the effects of each of the listening modes
see "Listening Mode Effects". For listening modes
selectable for each of the audio formats in the input
signals, refer to "Selectable Listening Modes".
When you press PURE AUDIO on the front of the unit, the
display and analog video circuits are turned off, and the
unit switches to the Pure Audio listening mode to provide
purer sound. Selecting this mode lights the PURE AUDIO
indicator on the unit. Pressing the button again reselects
the previous listening mode.
•
Selecting the Pure Audio listening mode turns off the
analog video circuitry, so the video signals input through
the jacks other than the HDMI input jack cannot be
displayed on the TV.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo TX-RZ820 and is the answer not in the manual?

Onkyo TX-RZ820 Specifications

General IconGeneral
THX-certifiedTHX Select
Display-
Product colorBlack
Audio decodersDSD, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby TrueHD
Audio amplifierYes
Center speaker impedance16 Ω
HDMI in7
Remote (IR) input1
Composite video in2
Bluetooth version4.1
Bluetooth profilesA2DP, AVRCP
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM, PLL
Preset stations quantity40
Internet radio services supportedDeezer, Pandora, Spotify, Tidal, TuneIn
Impedance6 Ω
Receiver typeSurround
Frequency range5 - 100000 Hz
Pre-out channels7.2
Input sensitivity200 mV
Audio output channels7.2 channels
Signal-to-Noise Ratio (SNR)106 dB
Total Harmonic Distortion (THD)0.08 %
Dynamic power per channel (3 Ohm)300 W
Dynamic power per channel (4 Ohm)250 W
Dynamic power per channel (8 Ohm)150 W
Power output per channel (20-20KHz@8 Ohm)- W
Audio formats supportedAIFF, ALAC, DSD, FLAC, PCM, WAV
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
Supported video modes480i, 480p
Headphone connectivity6.3 mm
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.15 W
Power consumption (typical)650 W
Package weight17000 g
Cables includedAC
Card reader integratedNo
Weight and Dimensions IconWeight and Dimensions
Depth395 mm
Width435 mm
Height201.5 mm
Weight14000 g
