53
> Network Functions > Specifications > Advanced Setup > Listening Modes
Troubleshooting Supplementary Information, etc�|
> Basic Manual
Spotify
Spotify Connect play is possible by connecting this unit to
the same network as a smart phone or tablet.
•
To play Spotify Connect, you need to install the Spotify
application on your smartphone or tablet. You also need
to create a Spotify premium account.
•
Refer to the following for Spotify settings:
www.spotify.com/connect/
Playing Back
1. Connect the smartphone to the access point that this
unit is connected to.
2. Start the Spotify app.
3. Play the track in the Spotify app, then after switching to
the screen for controlling play, tap "Devices Available" at
the bottom of the screen.
DevicesAvailable
Device
4. Select this unit.
5. This unit turns on automatically and the input selector
changes to NET and streaming of Spotify starts.
•
If "5. Hardware" - "Power Management" - "Network
Standby" is set to "Off" in the Setup menu, manually
turn the unit on and then press NET on the remote
controller.
Notes for using multi-zone (for compatible
models only)
•
To enjoy Spotify music in a separate room, manually
select "NET" as the input of the separate room. After
doing that, select this unit with the Spotify app.
•
Volume adjustment with the Spotify app is possible only
for speakers connected to the ZONE speaker terminals
or when the volume of the audio device in the other
room is configured so that its volume can be adjusted
on this unit. Adjust the volume on the audio equipment
in the other room in any other case.
•
To enjoy Spotify music in the main room after playing
it in a separate room, select "NET" as the input of the
main room.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo TX-RZ820 and is the answer not in the manual?

Onkyo TX-RZ820 Specifications

General IconGeneral
THX-certifiedTHX Select
Display-
Product colorBlack
Audio decodersDSD, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby TrueHD
Audio amplifierYes
Center speaker impedance16 Ω
HDMI in7
Remote (IR) input1
Composite video in2
Bluetooth version4.1
Bluetooth profilesA2DP, AVRCP
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM, PLL
Preset stations quantity40
Internet radio services supportedDeezer, Pandora, Spotify, Tidal, TuneIn
Impedance6 Ω
Receiver typeSurround
Frequency range5 - 100000 Hz
Pre-out channels7.2
Input sensitivity200 mV
Audio output channels7.2 channels
Signal-to-Noise Ratio (SNR)106 dB
Total Harmonic Distortion (THD)0.08 %
Dynamic power per channel (3 Ohm)300 W
Dynamic power per channel (4 Ohm)250 W
Dynamic power per channel (8 Ohm)150 W
Power output per channel (20-20KHz@8 Ohm)- W
Audio formats supportedAIFF, ALAC, DSD, FLAC, PCM, WAV
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
Supported video modes480i, 480p
Headphone connectivity6.3 mm
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.15 W
Power consumption (typical)650 W
Package weight17000 g
Cables includedAC
Card reader integratedNo
Weight and Dimensions IconWeight and Dimensions
Depth395 mm
Width435 mm
Height201.5 mm
Weight14000 g
