52
> Network Functions > Specifications > Advanced Setup > Listening Modes
Troubleshooting Supplementary Information, etc�|
> Basic Manual
LINKS
Internet Radio
You can use internet radio services such as TuneIn Radio,
Pandora, Deezer, and TIDAL by connecting this unit to a
network that has an internet connection.
•
Depending on the internet radio service, the user may
need to register from their computer first. Refer to the
websites for each of the services for details about them.
•
Functionality may be introduced by firmware updates
and service providers may cease services, meaning
that some network services and content may become
unavailable in the future.
Playing Back
1. Switch the input on the TV to that assigned to the unit.
2. Press NET on the remote controller to display a list of
Network Functions on the TV.
3. Select the internet radio service you want with the
cursors of the remote controller and press ENTER to
confirm your selection.
4. Follow the on-screen instructions, using the cursors
on the remote controller to select radio stations and
programs, then press ENTER to play.
•
To return to the previous screen, press
.
Internet radio service menus
You can register certain stations as your favorites or delete
stations you have registered from your favorites. The menu
displayed depends on the service currently selected.
Menu icons
are displayed at the bottom right of the
screen while playing a station. When just this icon is
displayed, you can display the menu on the screen just by
pressing ENTER on the remote controller. When multiple
icons are displayed, select an icon with the cursors of
the remote controller and press ENTER.
Regarding the TuneIn Radio Account
Creating an account on the TuneIn Radio website
(tunein.com) and logging in it from the unit allows you
to automatically add your favorite radio stations and
programs to your "My Presets" on the unit as you follow
them on the website. "My Presets" are displayed in the
level under TuneIn Radio.
To display a radio station registered in "My Presets", you
must log into TuneIn Radio from the unit. To log in, select
"Login" - "I have a TuneIn account" in the "TuneIn Radio"
top list on the unit, and then enter your user name and
password.
•
If you select "Login" on this unit, you can use the
displayed registration code to associate this device on
the My Page section of the TuneIn Radio website so
that you can login to "Login" - "Login with a registration
code" without having to enter your user name and
password.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo TX-RZ820 and is the answer not in the manual?

Onkyo TX-RZ820 Specifications

General IconGeneral
THX-certifiedTHX Select
Display-
Product colorBlack
Audio decodersDSD, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby TrueHD
Audio amplifierYes
Center speaker impedance16 Ω
HDMI in7
Remote (IR) input1
Composite video in2
Bluetooth version4.1
Bluetooth profilesA2DP, AVRCP
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM, PLL
Preset stations quantity40
Internet radio services supportedDeezer, Pandora, Spotify, Tidal, TuneIn
Impedance6 Ω
Receiver typeSurround
Frequency range5 - 100000 Hz
Pre-out channels7.2
Input sensitivity200 mV
Audio output channels7.2 channels
Signal-to-Noise Ratio (SNR)106 dB
Total Harmonic Distortion (THD)0.08 %
Dynamic power per channel (3 Ohm)300 W
Dynamic power per channel (4 Ohm)250 W
Dynamic power per channel (8 Ohm)150 W
Power output per channel (20-20KHz@8 Ohm)- W
Audio formats supportedAIFF, ALAC, DSD, FLAC, PCM, WAV
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
Supported video modes480i, 480p
Headphone connectivity6.3 mm
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.15 W
Power consumption (typical)650 W
Package weight17000 g
Cables includedAC
Card reader integratedNo
Weight and Dimensions IconWeight and Dimensions
Depth395 mm
Width435 mm
Height201.5 mm
Weight14000 g
