Orbit B-hyve User Guide

3
Note: The battery only functions to keep the
time and date in the event of power loss. Your
program is stored in non-volatile memory and
will not be lost if your timer loses power.
Set program is running
Water stations manually
Set clock time, Year, Month, and Day
Set time to begin watering
Set watering duration for each station
Set frequency of watering days
Adjust overall watering as a percentage
Turn all stations/functions off
Indicates a short in a zone
Indicates that water
budgeting has been adjusted
Solid–shows signal strength of Wi-Fi
and indicates that it is connected
Indicates a zone
is watering
There is no AC power
getting to the timer
Indicates a low battery
Timer Connected
Symbol
Rain Delay
Calendar
Programs
Remote Control or Home Button
Zone List
Settings
Next Zone
Stop Watering
Running Status/
Messaging
Weather/Temp.
Digital Display
B-hyve™ App
You will need to Install the B-hyve™ app
and create an account on your smart
device after the timer is installed.
Note: There is a wizard in the app to guide you
through initial set up of your sprinkler timer.
In addition, there are help icons throughout
the app with more information and useful tips.

Orbit B-hyve Specifications

Power

rated input voltage (Australia)	240V AC
rated input voltage (Europe)	230V AC
rated input voltage (USA)	120V AC
rated input current	0.15A
max load (AUS & EU)	24V AC 1 Amp
max load (USA)	24V AC 750 mA

Operating Environment

operating temperature range	32-167° F (0-75° C)
storage temperature range	32-176° F (0-80° C)
operating humidity range	0–80%
storage humidity range	0–90%
altitude	6, 500' (2, 000 meters)
