6
ALL CLOSED - BACK
ALL CLOSED - FRONT
Connecting Electrical Power
Once your B-hyve™ timer is plugged into the power
source, it will automatically look to pair with your smart
device. In the top left corner of the timer display the
Wi-Fi icon will begin a graduated blinking sequence. This
indicates that your timer is ready to pair with a smart
device. See page for details on how to pair timer.
If mounted in an outdoor location, shut the compartment
door to keep the timer safe from weather damage.
Indoor Locations—Insert the power cord
into an V electrical outlet.
Outdoor Locations—Insert the power cord into a
volt Ground Fault Interrupter (GFI) outlet.
Important: We recommend you consult an
electrician for hardwired installations.
Activating Battery
Timer includes one Lithium CR battery.
The battery will maintain your time and
date in case of an AC power loss.
Annual replacement is recommended
to avoid loss of programming.
Note: The battery alone will not operate the
valves in your sprinkler system. The sprinkler
timer has a built-in transformer that must be
connected to an AC voltage source.
WARNING: Risk of Fire, Explosion, and Electric Shock.
Replace battery with Hitachi Maxell Ltd, Type CR
only. Use of a different battery has the potential
for a risk of fire, explosion, and electric shock.
WARNING Chemical Burn Hazard. Keep
batteries away from children
WARNINGThis product contains a lithium button/
coin cell battery. If a new or used lithium button/coin
cell battery is swallowed or enters the body, it can
cause severe internal burns and can lead to death in as
little as hours. Always completely secure the battery
compartment. If the battery compartment does not close
securely, stop using the product, remove the batteries,
and keep it away from children. If you think batteries
might have been swallowed or placed inside any part
of the body, seek immediate medical attention.
Even used cells may cause injury.
Remove plastic strip
to activate battery
ALL OPEN - BOTTOM VIEW
ALL OPEN - RIGHT SIDE VIEW
