16
2.8.1 Chimney liner installation
To install of the chimney liner, the preferred methods are those found in Section 2.8.1.1. Use a
liner offset adapter (Section 2.8.1.2) only as a last resort.
2.8.1.1 If the chimney liner does align with the insert’s flue outlet, you have two options:
A) Install the chimney liner starter adapter, provided with the chimney liner. Follow the
chimney liner starter adapter manufacturer's instructions.
In order to connect the chimney liner starter adapter to the flue outlet, you can install the
brackets with the screws that are in the instruction manual kit.
Using a powered driver, secure the three brackets with the three screws provided 30131
on top of the insert in the three holes in front of the flue outlet. The long end of the
brackets must be attached to the insert. Insert the chimney liner into the flue collar of the
unit and secure the liner to the brackets with three self-tapping screws (not included).
B) You can get from your dealer a liner fixation system (AC02006), sold separately. Follow
the installation instructions provided with the liner fixation system.
