5
1.3 Door overlay installation
In order to complete the assembly of your Osburn 2400 wood insert, you need to install the door
overlay. See figure 1 below for installation instructions:
Figure 1
1- Position the overlay on the door frame and fix it in place from behind using the 4
screws.
Note: It is not necessary to remove the glass or any other component to install the overlay.
