To Set the Offset
Select Offset in the right menu (if Offset is not displayed, select Low Level and select it
again to switch to Offset). Set the parameter in the right menu.
To Set the High Level
Select High Level in the right menu (if High Level is not displayed, select Amplitude
and select it again to switch to High Level). Set the parameter in the right menu.
To Set the Low Level
Select Low Level in the right menu (if Low Level is not displayed, select Offset and
select it again to switch to Low Level). Set the parameter in the right menu.
To Output Square Signals
The parameters of Square waveform are: Frequency/Period, Start Phase, Amplitude/High
Level, Offset/Low Level.
To set the Frequency/Period, Start Phase, Amplitude/High Level, Offset/Low Level, please
refer to To Output Sine Signals on page 100.
To Output Ramp Signals
The parameters of Ramp waveform are: Frequency/Period, Start Phase, Amplitude/High
Level, Offset/Low Level, Symmetry.
To set the Frequency/Period, Start Phase, Amplitude/High Level, Offset/Low Level, please
refer to To Output Sine Signals on page 100.
To Set the Symmetry of Ramp
Select Symmetry in the right menu of Ramp. Set the parameter in the right menu.
To Output Pulse Signals
The parameters of Pulse waveform are: Frequency/Period, Start Phase, Amplitude/High
Level, Offset/Low Level, Width/Duty Cycle.
To set the Frequency/Period, Start Phase, Amplitude/High Level, Offset/Low Level, please
refer to To Output Sine Signals on page 100.
To Set the Pulse Width of Pulse
Select Width in the right menu (if Width is not displayed, select Duty Cycle and select it
again to switch to Width). Set the parameter in the right menu.
To Set the Duty Cycle of Pulse
Select Duty Cycle in the right menu (if Duty Cycle is not displayed, select Width and
select it again to switch to Duty Cycle). Set the parameter in the right menu.
To Output Arbitrary Signals
The menu items of Arbitrary waveform are: Frequency/Period, Start Phase,
