3.7. CS-F50DD2E5 CU-B50DBE8
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F50DD2E5 CU-B50DBE8
Cooling Capacity kW 13.5
BTU/h 46,000
Heating Capacity kW 15.0
BTU/h 51,100
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min Hi 45 Hi 96
cfm Hi 1590 Hi 3387
External Static Pressure Pa Hi 98 -
mmAq Hi 10.0
Outside Dimension (H x W x D) mm 360 x 1000 x 650 1170 x 900 x 320
inch 14-3/16 x 39-3/8 x 25-19/32 46-1/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 48 (106) 102 (225)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm O.D Ø 32 I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole single phase brushless motor
Rated Output kW - 4.5
Fan Type, Number of Set Sirocco Fan, 2 Mix flow fan - 2
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.27 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Louvre-fin type (3 x 18 x 13) Corrugate-fin type (2 x 44 x 20)
Refrigerant Control - Exp. Valve
Refrigerant Oil (Charged) cm
3
- FV68D (1500)
Refrigerant (Charged) R410A kg (oz) - 3.4 (120)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling : Hi 49 Lo 45 Cooling 56, Heating 57
Heating : Hi 47 Lo 44
Power level dB Cooling : Hi 64 Lo 60
Heating : Hi 62 Lo 59
Cooling 70, Heating 71
Moisture Removal L/h (Pt/h) 8.6 (18.1)
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by ISO5151
Volts V 380 400 415
Phase 3N 3N 3N
Power Consumption kW Cool 5.31 5.36 5.46
Heat 5.08 5.13 5.18
Running Current A Cool 8.8 8.9 9.1
Heat 8.3 8.5 8.7
Starting Current A 55 58 61
Power Factor % Cool 92 87 83
Heat 93 87 83
EER W/W 2.54 2.52 2.47
COP W/W 2.95 2.92 2.90
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3N~380V, 400V, 415V 50Hz
12
