Panasonic CS-F43DD2E5 Service Manual

3 SPECIFICATION
3.1. CS-F24DD2E5 CU-B24DBE5
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F24DD2E5 CU-B24DBE5
Cooling Capacity kW 6.6
BTU/h 22,500
Heating Capacity kW 7.1
BTU/h 24,200
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min Hi 22 Hi 60
cfm Hi 777 Hi 2120
External Static Pressure Pa Hi 69 -
mmAq Hi 7.0
Outside Dimension (H x W x D) mm 290 x 1000 x 500 795 x 900 x 320
inch 11-13/32 x 39-5/16 x 19-21/32 31-5/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 35 (78) 69 (152)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm O.D Ø 32 I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole single phase brushless motor
Rated Output kW - 2.2
Fan Type, Number of Set Sirocco fan, 2 Mix flow fan - 1
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.135 0.07
Air-heat Exchanger (Row x Stage x FPI) Louvre-fin type (3 x 12 x 15) Corrugate-fin type (2 x 36 x 19)
Refrigerant Control - Exp. Valve
Refrigerant Oil (Charged) cm
3
- FV50S (1130)
Refrigerant (Charged) R410A kg (oz) - 1.7 (60)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling : Hi 45 Lo 41 Cooling 50, Heating 51
Heating : Hi 43 Lo 39
Power level dB Cooling : Hi 61 Lo 57
Heating : Hi 59 Lo 55
Cooling 66, Heating 67
Moisture Removal L/h (Pt/h) 3.80 (8.0)
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by ISO5151
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cool 2.61 2.64 2.70
Heat 2.45 2.53 2.62
Running Current A Cool 12.9 13.1 13.4
Heat 11.6 11.9 12.3
Starting Current A 59 62 65
Power Factor % Cool 92 88 84
Heat 96 92 89
EER W/W 2.53 2.50 2.44
COP W/W 2.9 2.81 2.71
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
