Panasonic CS-F43DD2E5 Service Manual

NO. PART DESCRIPTION QTY. CU-B34DBE5 CU-B34DBE8 CU-B43DBE8 CU-B50DBE8
1 BASE PAN ASSY 1 CWD52K1103 ← ← ←
2 COMPRESSOR 1 JT125G-P4V1 JT125G-P4Y1 JT160G-P4Y1 JT170G-P4Y1
3 ANTI-VIBRATION BUSHING 3 CWH501081 ← ← ←
4 NUT COMPRESSOR MOUNT 3 CWH561049 ← ← ←
5 CRANKCASE HEATER 1 CWA341025 ← ← ←
6 CONDENSER COMPLETE 1 CWB32C1703 ← ← ←
7 TUBE ASSY(CAPILLARY TUBE) 1 CWT07K1294 ← ← ←
8 4-WAYS VALVE COMPLETE 1 CWB00C1029 CWB00C1030 CWB00C1029 ←
9 4-WAYS VALVE 1 CWB001046 ← ← ←
10 DISCHARGE MUFFLER 1 CWB121001 ← ← ←
11 HEATING PRESSURE SWITCH 1 CWA101007 ← ← ←
12 3-WAYS VALVE (GAS) 1 CWB011251 ← ← ←
13 STRAINER 1 CWB111036 ← ← ←
14 PRESSURE SWITCH 1 CWA101012 ← ← ←
15 3-WAYS VALVE (LIQUID) 1 CWB011292 ← ← ←
16 TUBE ASSY(STRAINER, EXP.VALVE) 1 CWT023939 ← ← ←
17 RECEIVER ASSY 1 CWB14K1013A ← ← ←
18 SOUND PROOF MATERIAL 1 CWG302335 ← ← ←
19 SOUND PROOF MATERIAL 1 CWG302336 ← ← ←
20 V-COIL COMPLETE 1 CWA43C2211 ← ← ←
21 V-COIL COMPLETE 1 CWA43C2177J ← ← ←
22 HOLDER-SERVICE VALVE 1 CWD911425 ← ← ←
23 SOUND PROOF BOARD 1 CWH151079 ← ← ←
24 PIPING SENSOR 1 CWA50C2293 ← ← ←
25 PIPING SENSOR 1 CWA50C2294 ← ← ←
26 SPRING FOR SENSOR 2 CWH711010 ← ← ←
27 CABINET REAR PLATE COMPLETE 1 CWE02C1030 ← ← ←
28 CONTROL BOARD ASSY 1 CWH10K1063 CWH10K1064 ← ←
29 TERMINAL BOARD ASSY 1 CWA28K1085J CWA28K1109 ← ←
30 TERMINAL BOARD ASSY 1 CWA28K1076J ← ← ←
31 CAPACITOR-FM (3.0µF/460V)(3.5µF/460V) 2 DS461305QP-A ← ← DS461355QP-A
32 ELECTRO MAGNETIC SWITCH 1 K6C5E8A00001 CWA001026 ← ←
33 ELECTRONIC CONTROLLER-MAIN 1 CWA73C1906 CWA73C1907 CWA73C1908 CWA73C1909
34 TRANSFORMER 1 CWA401060 ← ← ←
35 BRACKET FAN MOTOR ASSY 1 CWD54K1023 ← ← ←
36 SCREW-FAN MOTOR BRACKET 2 CWH551040J ← ← ←
37 FAN MOTOR AC 70W SINGLE 1 CWA951366 ← ← ←
38 FAN MOTOR AC 70W SINGLE 1 CWA951403 ← ← ←
39 SCREW-FAN MOTOR BRACKET 2 CWH551040J ← ← ←
40 PROPELLER FAN ASSY 2 CWH03K1017 ← ← ←
41 NUT-PROPELLER FAN 2 CWH561038J ← ← ←
42 CABINET TOP PLATE COMPLETE 1 CWE03C1039 ← ← ←
43 PIPE COVER (FRONT) 1 CWD601074A ← ← ←
44 PIPE COVER (BACK) 1 CWD60K1003A ← ← ←
45 CABINET FRONT PLATE 1 CWE061092A ← ← ←
46 DISCHARGE GRILLE 2 CWE201075 ← ← ←
47 CABINET SIDE PLATE ASSY 1 CWE04K1022A ← ← ←
48 WIRE NET 1 CWD041064A ← ← ←
49 CABINET FRONT PLATE COMPLETE 1 CWE06C1132 ← ← ←
50 HANDLE 2 CWE161008 ← ← ←
51 LEADWIRE-COMPRESSOR 1 CWA67C5903 CWA67C5916 ← ←
52 WIRING COVER AND BAND 1 CWH82C1105 ← ← ←
53 INSTALLATION INSTRUCTION 1 CWF612864 ← ← ←
54 ACCESSORY COMP. (DRAIN ELBOW) 1 CWG87C2030 ← ← ←
55 CAPACITOR-COMP. (35µF/440V) 2 DS441356CPNE - - -
56 HOLDER CAPACITOR 2 CWH30176 - - -
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
143
