106
VQT2J45
Specifications
§1
Finalising is necessary for compatible playback.
§2
Conforming to IEC62107
This unit is not compatible with “Chaoji Video CD” available on the market
including CVD, DVCD and SVCD that do not conform to IEC62107.
§
3
Video Recording conversion and transfer is possible from Panasonic digital
video camera with HDD etc, to HDD or DVD-RAM disc. After Video Recording
conversion and transfer to HDD or DVD-RAM disc, the playback is possible.
§4
Includes miniSD or miniSDHC Cards. (A miniSD or miniSDHC
adaptor needs to be inserted.) Includes microSD or microSDHC
Cards. (A microSD or microSDHC adaptor needs to be inserted.)
§5
Long file name is unsupported.
§6
Video Recording conversion and transfer is possible from card to
HDD or DVD-RAM disc. After Video Recording conversion and
transfer to HDD or DVD-RAM disc, the playback is possible.
Power supply: AC 220 V to 240 V, 50 Hz
Power consumption: Approx. 40 W
Standby mode:
(“Power Save in Standby” is
activated and “RF OUT ( Aerial
Signal )” is set to “Off”.)
Approx. 0.5 W
(“Power Save in Standby” is
not activated)
Approx. 16 W
Recordable discs:
DVD-RAM: 2X SPEED (Ver. 2.0), 2–3X SPEED (Ver. 2.1)
2–5X SPEED (Ver. 2.2)
DVD-R (SL): 1X SPEED (Ver. 2.0), 1–4X SPEED (Ver. 2.0)
1–8X SPEED (Ver. 2.0), 1–16X SPEED (Ver. 2.1)
DVD-R (DL): 2–4X SPEED (Ver. 3.0), 2–8X SPEED (Ver. 3.0)
DVD-RW: 1X SPEED (Ver. 1.1), 1–2X SPEED (Ver. 1.1)
2–4X SPEED (Ver. 1.2), 2–6X SPEED (Ver. 1.2)
+R (SL): 2.4X SPEED (Ver. 1.0), 2.4–4X SPEED (Ver. 1.1)
2.4–8X SPEED (Ver. 1.2)
2.4–16X SPEED (Ver. 1.3)
+R (DL): 2.4X SPEED (Ver. 1.0), 2.4–8X SPEED (Ver. 1.1)
+RW: 2.4X SPEED (Ver. 1.1), 2.4–4X SPEED (Ver. 1.2)
Recording system:
DVD-RAM: DVD Video Recording format
DVD-R: DVD-Video format
DVD-R DL (Dual Layer): DVD-Video format
DVD-RW: DVD-Video format
+R
+R DL (Double Layer)
+RW
Recording time:
Max. 8 hours (using 4.7 GB disc)
XP: Approx. 1 hour SP: Approx. 2 hours
LP: Approx. 4 hours EP: Approx. 6 hours or 8 hours
Maximum Approx. 441 hours with 250 GB HDD (EP 8 hours mode)
XP: Approx. 55 hours SP: Approx. 110 hours
LP: Approx. 221 hours EP: Approx. 331 hours/441 hours
Playable discs:
DVD-RAM:
DVD Video Recording format, JPEG
DVD-R:
DVD-Video format, MP3
§1
, WMA
§1
,
JPEG
§1
, DivX
§1
DVD-R DL (Dual Layer):
DVD-Video format, MP3
§1
, WMA
§1
,
JPEG
§1
, DivX
§1
DVD-RW: DVD Video Recording format,
DVD-Video format
+R
+R DL (Double Layer)
+RW
DVD-Video, CD-Audio (CD-DA), Video CD, SVCD
§2
CD-R/CD-RW:
CD-DA
§1
, Video CD
§1
, SVCD
§1, §2
,
MP3
§1
, WMA
§1
, JPEG
§1
, DivX
§1
Internal HDD capacity: 250 GB
Optical pick-up:
System with 1 lens, 2 integration units
(662 nm wavelength for DVDs, 780 nm wavelength for CDs)
LASER Specification
Class 1 LASER Product
Wave Length: 780 nm (CDs)
662 nm (DVDs)
Laser Power: No hazardous radiation is emitted
with the safety protection
Television system
Tuner System: DVB-T
Channel Coverage: UK
UHF: 21 to 68 ch
RF converter output: Not provided
Video
Video system:
PAL colour signal, 625 lines, 50 fields
NTSC colour signal, 525 lines, 60 fields
Recording system: MPEG2 (Hybrid VBR)
Video In (PAL/NTSC): AV1/AV2 (21 pin), AV3 (pin jack)
1 Vp-p 75 ≠, termination
S-Video In (PAL/NTSC): AV2 (21 pin), AV3 (S terminal)
1 Vp-p 75 ≠, termination
RGB In (PAL): AV2 (21pin) 0.7 Vp-p (PAL) 75 ≠,
termination
Video Out (PAL/NTSC): AV1/AV2 (21 pin), Video Out (pin
jack) 1 Vp-p 75 ≠, termination
RGB Out (PAL/NTSC): AV1 (21 pin), 0.7 Vp-p (PAL) 75 ≠,
termination
VHS
Recording format: VHS Video Cassette System
Standard with FM audio
Heads: 4 Helical Scan Heads for Video
2 Helical Scan Heads for FM audio
1 Fixed Head for Normal audio
Tape speed/Recording time (with E-240 tape):
PAL: SP: 23.39 mm/s, 240 min
LP: 11.7 mm/s, 480 min
EP: 7.8 mm/s, 720 min
NTSC: SP: 33.35 mm/s, 168 min
EP: 11.12 mm/s, 505 min
Audio
Recording system:
Dolby Digital 2 ch, Linear PCM (XP mode)
Audio In: AV1/AV2 (21 pin), AV3 (pin jack)
Input Level: Standard: 0.5 Vrms,
Full scale: 2.0 Vrms at 1 kHz
Input Impedance: More than 10 k≠
Audio Out:
AV1/AV2 (21 pin), Audio Out (pin jack)
Output Level: Standard: 0.5 Vrms,
Full scale: 2.0 Vrms at 1 kHz
Output Impedance: Less than 1 k≠
Digital Audio Out: Optical terminal (PCM, Dolby
Digital, DTS, MPEG)
USB
USB port: Type A: 1 pc
USB standard: USB 2.0 High Speed
Format: FAT16, FAT32
Video (SD-Video)
§3
Codec: MPEG2 (SD-Video Entertainment
Video Profile)
File Format: SD-Video format conforming
HDMI Output: 19 pin type A: 1pc
HDMI
TM
(V.1.3a with Deep Colour)
This unit supports “HDAVI Control 5” function.
SD Card
Slot: SD Memory Card Slot: 1pc
Compatible media:
SD Memory Card
§4
, SDHC
Memory Card
§4
, MultiMediaCard
Format:
FAT12, FAT16
§5
(In case of SD
Memory Card, MultiMediaCard)
FAT32
§
5
(In case of SDHC Memory Card)
Still Picture (JPEG)
Image File Format: JPEG conforming DCF (Design
rule for Camera File system)
Compatible pixels: Between 34a34 and 6400a6400
Sub sampling: 4:2:2, 4:2:0
Video (SD-Video)
§6
Codec: MPEG2 (SD-Video Entertainment
Video Profile)
File Format: SD-Video format conforming
Others
Regional Code: # 2
Operating temperature range: 5 oC to 40 oC
Operating humidity range:
10 % to 80 % RH (no condensation)
Dimensions (WkHkD): 430 mma84 mma335 mm
(excluding the projecting parts)
430 mma84 mma346 mm
(including the projecting parts)
Mass: Approx. 6.1 kg
Notes
≥Specifications are subject to change without notice.
≥Usable capacity will be less (SD Card).
