- 11 -
Before Use
Names of the Components
1Flash (P56)
2 Self-timer indicator (P63)
AF assist lamp (P116)/LED light (P90)
3Lens (P172)
4 LCD monitor (P54, 167)
5 Status indicator (P20, 32, 37)
6 Playback button (P26)
7 [MENU/SET] button (P24)
8 [DISPLAY] button (P54)
9 [Q.MENU] (P29)/Delete (P52) button
10 Motion picture button (P37)
11 Mode dial (P37)
12 Cursor buttons
A: 3/Exposure compensation (P64)/
Auto bracket (P65)/White balance
fine adjustment (P105)
B: 4/Macro mode (P61)
AF Tracking (P42, 109)
C: 2/Self-timer button (P63)
D: 1/Flash setting button (P56)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
21 3
4512
6897
10
11
