(1) Camera lens
(2) Light (for night vision)
(3) Speaker
(4) Mic
(5) Status indicator (Calling/Talking/Door opening)
(6) Terminal for bus wiring
(7) Vigik module input
(8) K-OUT for NC/NO
1. Specifications
1-6. Lobby Station-2
(5)
(1)
(2)
(4)
(3)
(9) Dip switch for setting
(10) Connector cable for module connection
(11) Connector for DDA module (TBD)
(12) Connector for 12key module (TBD)
(13) Power switch
(14) Terminal for DC in
(15) K-IN
(16) Terminal foe star shape wiring
(9) (10)
(13)
(14)
(15)
(16)
(6)
(7)
(8)
(11)
(12)
