Panasonic VL-MWD501 User Manual

IP Video Intercom Product
2. Specifications
4-4. System Overview
4. Installation
2 wiring style are available.
• Suitable for small size apartment
• Easy to replace from the door chime equipment
• Suitable for medium size apartment
• Easy to utilize the riser to wire the bus
Wiring distance
Lobby Station – Room Monitor  Max.100m (φ0.65) / Max.200m (φ1.20)
Wiring distance
Lobby Station – Distributor  Max.100m (φ0.65) / Max.200m (φ1.20)
Distributor – Room Monitor  Max.100m (φ0.65) / Max.200m (φ1.20)
*Example System configuration of Bus-powered type Monitors in figures. The configuration of PSUs depends on system requirement and specification of devices selected in each system.
Star Shape Wiring
Bus Wiring
31
