3–3
3.2 Mechanical Structural Diagram
Motor
Output Tray
Laser Unit
Feeder Tray
Pickup Roller
Separator Component
Clutch Gear
Supply Roller
Developing Roller
Transfer Roller
OPC (photosensitive drum)
Charge Roller
Heating Roller
Pressure Roller
Delivery Roller
Mixing Bracket
Halogen Light
