4.1 Parts
Fuser Unit
Top Cover Assembly
Rear Cover
Operator Panel Assembly
Right-Side Cover
Transfer Roller
Main Motor
Sensor Board
Pick-Up Roller
Separator Pad
Control Board
High Voltage Power Supply Board
Printer Frame
Laser Uint
Left-Side Cover
Driver System
Paper Feed Solenoid
Paper Feed Clutch
Front Cover
Paper Tray
