INTELLIFLO3™ VSF / INTELLIPRO3™ VSF Variable Speed and Flow Pump Installation and Maintenance Guide
Item Description
Almond
Part #
Black
Part #
1 Drive Cover Assembly 356214z 356349z
2 Field Wiring Compartment Kit 356096Z 356337z
3 Blank Controller Kit 356101z 356338z
4 Touchscreen Controller Kit 356159z 356348z
5 Touchscreen Lid 356099z 356339z
6 Relay Control Board Kit 356365z
7 Antenna 356226z
- 4-Pin Connector, RS-485 8023304
9 6-Pin Connector, Relay Control Board 8023306
10 Controller Screw (x4) 356215z
11 Drive and Drive Hardware Kit 356162z
12 Drive Hardware Kit 357865
13 7/8" Plug, Drive (x3) 356219z
14 1" Bushing, Low Voltage, Drive 356320z
15 Motor Kit 356164s
16 Motor Bracket Kit 356167z
17 Motor Foot Kit 356149z 356341z
18 Motor Shroud Kit 357867 357868
19 Motor Fan Kit 356232z
20 Bonding Lug 356166z
21 Motor Foot Screw 356221z
22 Motor Bolts (x4) 074165z
23 Seal Plate Kit 356090z 356333z
24 Seal Plate O-ring 356148z
25 Shaft Seal 356210s
26 Impeller 356176z
27 Diffuser 356155z
28 Diffuser Screws (x3) 356213z
29 Diffuser O-ring 356190z
30 Strainer Basket 074162z
31 Lid Assembly 356172z 356368z
32 Lid O-ring 356189z
33 Strainer Pot Kit 356174z 356346z
34 Drain Plug O-ring (x2) 192115z
35 Drain Plug and O-ring (x2) 071131z
36 Seal Plate-to-Strainer Pot Bolts (x6) 074164z
- Seal Kit 357871
- Union Kit 351157
- Union O-ring 6020018
- Riser Plate Kit - Thin (A/B Base) 357833z
- Riser Plate Kit - Thick (C Base) 357831z
- Riser Plate Kit - Both 357832z
(-) Not Shown
Pump Parts List (1.5 HP Models)
Item Description
Almond
Part #
Black
Part #
1 Drive Cover Assembly 356214z 356349z
2 Field Wiring Compartment Kit 356096z 356337z
3 Blank Controller Kit 356101z 356338z
4 Touchscreen Controller Kit 356159z 356348z
5 Touchscreen Lid 356099z 356339z
6 Relay Control Board Kit 356365z
7 Antenna 356226z
- 4-Pin Connector, RS-485 8023304
9 6-Pin Connector, Relay Control Board 8023306
10 Controller Screw (x4) 356215z
11 Drive and Drive Hardware Kit 356163z
12 Drive Hardware Kit 357865
13 7/8" Plug, Drive (x3) 356219z
14 1" Bushing, Low Voltage, Drive 356320z
15 Motor Kit 356165s
16 Motor Bracket Kit 356167z
17 Motor Foot Kit 356149z 356341z
18 Motor Shroud Kit 357869 357870
19 Motor Fan Kit 357866z
20 Bonding Lug 356166z
21 Motor Foot Screw 356221z
22 Motor Bolts (x4) 074165z
23 Seal Plate Kit 356091z 356345z
24 Seal Plate O-ring 356173z
25 Shaft Seal 356210s
26 Impeller 356177z
27 Diffuser 356156z
28 Diffuser Screws (x3) 356213z
29 Diffuser O-ring 356190z
30 Strainer Basket 400007z
31 Lid Assembly 356172z 356368z
32 Lid O-ring 356189z
33 Strainer Pot Kit 356175z 356347z
34 Drain Plug O-ring (x2) 192115z
35 Drain Plug and O-ring (x2) 071131z
36 Seal Plate-to-Strainer Pot Bolts (x8) 074164z
- Seal Kit 357872
- 2" / 2.5" Union Kit 410028
- 3" Union Kit 410029
- Union O-ring - Diamond Seal 410016z
- Riser Plate Kit - Thin (A/B Base) 357833z
(-) Not Shown
Pump Parts List (3 HP Models)
