Adjustment
16
13.04.11 Bobbin lifter (make this adjustment on both bobbin lifters with the Pfaff 1244).
Rule
The needle thread should not become jammed between the bobbin lifter 1 and the bobbin
case base 3 or between the retaining lug 4 and the retaining dog of the needle plate.
Fig. 13 -11
O Thread the machine and insert the testing material.
O Fit the roller presser.
O Sew a few stitches by turning the handwheel and carry out a check according to
the rule.
O Turn the bobbin lifter 1 ( screw 2 ) according to the rule.
2
1
3
4
