7 - 2
Controls
Fig. 7 - 03
0
1
2
3
Fig. 7 - 04
1
7.03 Pedal
0 = Neutral position
1 = Sewing
2 = Raise presser foot
3 = Trim sewing threads
For other pedal functions
please refer to the instruction
manual of the motor
manufacturer.
7.04 Knee switch
● By operating knee switch 1 it is possible
to alternate between two pre-selected
feed stroke settings.
For the high stroke setting the
speed is reduced.
The function of the knee
switch can be changed; please
refer to the instruction manual
of the motor manufacturer.
