9 - 4
Setting up
Fig. 9 - 04
+
-
1
2
4
3
5
Switch the machine off!
Danger due to unintentional
starting of the machine!
● Set take-up lever at its top position.
● Open bed slide, lift latch 1 and take out
the bobbin. Place the filled bobbin into
the hook so that the bobbin turns as
shown by the arrow when the thread is
pulled.
● Close latch 1 again.
● Pull the thread through slot 2, around
stop 3 and into hole 4. Close the bed
slide again.
● Regulate the bobbin-thread tension by
turning screw 5.
Do not run the machine with the bed slide open.
Danger of injury by moving parts.
9.04 Bobbin-changing/threading, and regulating the bobbin thread tension
