Pfaff 1525 User Manual

11 - 54
Adjustment
7 707 Needle position 6 0 - 239 185 185
(Start tension release signal 2)
725 Display on operating panel corresponds to
I = Actual speed I II
II = remaining stitches for bobbin thread
726 Counter for bobbin monitoring
I = activated II I
II = deactivated
727 Counter for bobbin monitoring brings
I = stop and signal at output Y36 II
II = signal at output Y36 without stop
793 Delay from "feed resetting on" to "cut"
for shortened trim stitch 0 - 2550 140 140
8 801 Reverse angle 30 30
9 988 Shortened trim stitch II I
For more information and displays see the motor instruction manual.
Group
Parameter
Description
Standard value with -926/07
Adjustm. range
Standard value with -926/06
