- First loosen the screw of the hydraulic hose of the
rear brake calliper.
- Unscrew and remove the screws fastening the
brake calliper to the carter.
- Detach the brake calliper from the wheel disc.
- Unscrew and remove the coupling screw of the
rear brake pipe.
NRG 50 Braking system
BRAK SYS - 193
