Refitting
Insert and screw the coupling screw of the rear
brake pipe.
- Position the brake calliper.
- Tighten to the specified torque the screws fas-
tening the brake calliper to the carter.
- Tighten to the specified torque the screw of the
hydraulic hose.
Braking system NRG 50
BRAK SYS - 194
