Fig. 12 - Dismantling the air cleaner
DISMANTLING THE SPARE WHEEL (Accessory)
For dismantling the spare wheel, remove the spare wheel cowl, following the instructions
given for engine cowl (page 17). For removing the spare wheel unscrew the bolt securing
the lower part of the plastic protection, then the two nuts « D » securing the wheel to the
upper part of the bracket. (fig. 14).
Fig. 13 A Fig. 13 B
Dismantling cooling hood from engine (A) and head (B).
