ACCELERATOR AND BRAKE PEDAL ASSEMBLIES Accelerator Pedal Adjustment
2003 Pioneer 1200/1200SE Gasoline Vehicle Maintenance and Service Manual Page 5-7
5
Figure 5-7 Accelerator Pedal Height Figure 5-8 Accelerator Pedal Adjustment
Figure 5-9 Accelerator Pedal Height Adjustment
Figure 5-10 Accelerator Cable and Electrical Box
GO
STOP
1
2
3
4
5
6
7
8
9
10
Correct pedal position
is 5-3/4-inch ± 1/4-inch
(14.6 cm ± 6 mm) from
floormat to back of
accelerator pedal.
