Pioneer VSX-C100 Service Manual

VSX-C100-S
48
1234
1234
C
D
F
A
B
E
5. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
1..FM/AM TUNER MODULE AXQ7232
NSP 1..COMPLEX 1 Assy AWM7673
2..POWER Assy AWX8042
2..6PA-JACK Assy AWX8043
2..DIGITAL IN Assy AWX8046
2..VIDEO Assy AWX8047
2..2PA-JACK Assy AWX8048
NSP 1..COMPLEX 2 Assy AWM7674
2..DSP Assy AWX8049
2..FRONT Assy AWX8050
2..SW Assy AWX8051
2..ENCODER Assy AWX8052
2..FRONT INPUT AWX8053
Mark No. Description Part No.
J
POWER ASSY
SEMICONDUCTORS
>
IC454 AEK7006
>
IC302 AEK7009
>
IC453 AEK7016
>
IC455 AEK7022
>
IC452 BA12T
>
IC451 NJM7805FA
>
IC201 NJM78M56FA
IC301 STK402-040
IC341 STK402-240
Q386, Q391 2SA1037K
Q384, Q385 2SC2412K
Q305, Q306, Q345 2SC2712
Q346, Q383 2SC2712
Q387, Q389, Q401 2SC2712
Q403, Q404 2SC2712
Q390, Q405 DTA124EK
Q406 DTA124EK
Q409, Q410 DTC124EK
Q201 DTC143EK
D201, D202, D203 1SS355
D301, D302 1SS355
D303, D304 1SS355
D305, D306, 1SS355
D341, D342, D343 1SS355
D344, D345 1SS355
D346, D381 1SS355
D382, D383 1SS355
D384, D385 1SS355
D386, D387 1SS355
D388, D401 1SS355
D403, D404 1SS355
D405, D406 1SS355
>
D452 D3SBA20(B)
>
D451 D5SBA20(B)
>
D205 S1VB20/F03
>
D453 S5566G(TPB2)
D455 UDZ20B
D204, D410 UDZS5.1B
D454 UDZS6.8B
COILS AND FILTERS
>
L101 ATF7018
L301, L302, L341 ATH-133
L342, L381 ATH-133
F451, F452 DTF1070
F453 DTF1070
SWITCHES AND RELAYS
RY301, RY341, RY381 ASR7008
RY401 ASR7008
>
RY101 ASR7013
CAPACITORS
>
C101 ACE7013
>
C102 ACG7033
C459, C460 ACH1237
C451, C452 ACH7161
C401, C403 CCSRCH101J50
C305, C306, C331 CCSRCH221J50
C345, C346 CCSRCH221J50
C383, C409 CCSRCH221J50
C323 CCSRCH331J50
C303, C304, C343 CCSRCH471J50
C344, C382 CCSRCH471J50
C309, C310 CCSRCH6R0D50
C311, C312, C349 CCSRCH6R0D50
C350, C351 CCSRCH6R0D50
C352, C385 CCSRCH6R0D50
C386 CCSRCH6R0D50
C202, C456 CEAT102M16
C313, C314 CEAT220M50
C353, C354 CEAT220M50
C457 CEAT221M25
Mark No. Description Part No.
