9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
8.9
FRONT SUSPENSION ASSEMBLY VIEW - WIDE FIXED CAMBER
q
Lower Control Arm to Fastener
d
Nut
40 ft-lbs (54 N·m)
w
Lower Control Arm Pivot Shaft
Push forward to remove all clearance prior to torquing
nuts
f
Washer
e
Nut
40 ft-lbs (54 N·m)
g
Lower Spherical Bearing
r
Nut
30 ft-lbs (41 N·m)
h
Retaining Ring
Retaining ring must be fully seated
t
Washer
j
Lower Control Arm to Spindle Fastener
y
Pivot Bushing
k
Spindle
u
Lower Control Arm
l
Washer
i
Upper Control Arm
1(
Nut
40 ft-lbs (54 N·m)
o
Upper Control Arm Pivot Shaft
Push forward to remove all clearance prior to torquing
nuts
2)
Bushing
a
Retaining Ring
Retaining ring must be fully seated
2!
Ski Pivot Bushing
s
Upper Spherical Bearing
STEERING / SUSPENSIONS
