TIRE TREAD DEPTH
Always replace tires when tread depth
is worn to 3 mm (1/8”) or less.
AXLE AND WHEEL NUT TORQUE SPECIFICATIONS
Inspect the following items occasionally for tightness, and if they've been
loosened for maintenance service. Do not lubricate the stud or the lug nut.
NUT TYPE LOCATION
NUT TORQUE
Lug Nut
(Aluminum
Wheels)
Front and Rear
120 ft-lbs (163 Nm)
Lug Nut (Tapered)
Front and Rear
180 ft-lbs (245 Nm)
WHEEL REMOVAL
1. Position the vehicle on a level surface.
2. Place the transmission in PARK. Stop the engine.
3. Loosen the wheel nuts slightly.
4. Elevate the side of the vehicle by placing a suitable stand under the frame.
5. Remove the wheel nuts and washers. Remove the wheel.
WHEEL INSTALLATION
WARNING
Improperly installed wheels can adversely affect tire wear and vehicle
handling, which can result in serious injury or death. Always ensure that all
nuts are torqued to specification. Do not service axle nuts that have a cotter pin
installed. Your dealer can assist.
111
MAINTENANCE
