ANTI-LOCK BRAKING SYSTEM – ABS (IF EQUIPPED)
1. Press and hold the Mode button to
enter the settings menu.
2. Use the toggle buttons to find the
ABS system “enable” or “disable”
setting. Press the Mode button to
select the desired setting.
3. The ABS symbol will appear on the
instrument cluster when the system
is enabled.
NOTICE
The ABS system can be disabled only if the rider is traveling at a speed below
30 km/h. The ABS system is automatically activated if travelling above 30 km/h
and cannot be disabled.
ENGINE ERROR CODES
The error screen displays only when the CHECK ENGINE indicator is on or
when it goes on and off during one ignition cycle. Error codes are not stored.
When the key is turned OFF, the code and message is lost, but will reappear if
the fault reoccurs after restarting the engine.
If the CHECK ENGINE lamp or the EPS lamp illuminates, retrieve the active
error codes from the display.
q
Failure Mode Indicator (FMI)
w
Suspect Parameter Number (SPN)
e
Code Count
1. Press and hold the MODE button to enter the settings menu.
2. Press either toggle button to cycle to the “DIAGCODE” option. Press MODE
to select.
3. More than one diagnostic code may be present. Press the toggle UP button
to see if more codes are present. Press MODE to select a code.
NOTICE
If the displayed code is an engine fault code, the CHECK ENGINE lamp will
blink. If the displayed code is an EPS fault code, the EPS lamp will blink.
66
FEATURES AND CONTROLS
