INSTRUMENT CLUSTER
NOTICE
High water pressure may damage components. Wash the vehicle by hand or
with a garden hose using mild soap. Certain products, including insect
repellents and chemicals, will damage the speedometer lens and other plastic
surfaces. Do not use alcohol to clean the instrument cluster. Do not allow
insect sprays to contact the lens. Immediately clean off any gasoline that
splashes on the instrument cluster.
q
Speedometer
w
Tachometer
e
Indicator Lamps
r
Mode Button
t
Toggle Buttons
y
Rider Information Center
SPEEDOMETER
The speedometer displays vehicle speed in either miles per hour (MPH) or
kilometers per hour (km/h).
TACHOMETER
The tachometer displays engine speed in revolutions per minute (RPM).
MODE BUTTON
Press and hold the MODE button
r
to enter or exit the settings menu. Press
and release the MODE button to cycle through Area 1 modes and to select an
item.
57
FEATURES AND CONTROLS
