101
MAINTENANCE AND LUBRICATION
Lubrication
Oil System
The oil dipstick and fill tube are located on the left side of the vehicle
To check the oil:
1. Set machine on a level
surface.
2. Start the engine and let
it idle for 20-30
seconds.
3. Stop the engine and lift
the lever lock (A) on
the dipstick. Remove
the dipstick and wipe it
clean.
4. Re-install the dipstick
completely, remove it
and read the oil level.
NOTE: Make certain
the dipstick is inserted
all the way into the
filler tube to keep the
angle and depth of stick
consistent.
5. Remove dipstick and check to see that the oil level is between the
full and add marks. Add oil as indicated by the level on the
dipstick. Do not overfill.
6. When reinstalling the dipstick, make certain to seat the lever lock.
SAFE
ADD 8 OZ
A
