107
MAINTENANCE AND LUBRICATION
Adjustments
Handlebar Adjustment
Your ATV has handlebars which
can be adjusted for your
personal fit.
1. To locate handlebar bolts,
it will be necessary to
remove the upper headlight
pod.
2. Loosen the four bolts.
3. Adjust handlebar to desired
height. Be sure handlebars do not hit gas tank or any other part of
machine when turned fully to left or right.
4. Torque handlebar adjuster block bolts to 10 to 12 ft. lbs.
NOTE: Tighten bolts so there is an equal gap at the front and rear of
the handlebar block. Improper gap will result in improper fit of upper
pod.
Improper adjustment of the handlebars or incorrect torquing of
the adjuster block tightening bolts can cause limited steering or
loosening of the handlebars, resulting in loss of control and
possible serious personal injury or death.
WARNING
