50
CONTROLS AND FEATURES
Controls
Fuel System
The fuel tank filler cap (1)
is located directly behind
the handlebar. Refer to
vehicle specifications on
page 7 for tank capacity.
Use either leaded or
unleaded gasoline with a
minimum pump octane
number of 87 (R+ M/2)
octane.
The fuel valve is located on
the left side panel and has
three positions:
OFF: For vehicle storage
and whenever transporting.
ON: For normal operation.
RES: For reserve supply in
the event of main supply
exhaustion.
NOTE: There is about a 7
to 10 mile (11.2 to 16 km)
range on reserve gas.
Always refill the gas tank
as soon as possible after
having used the reserve
supply.
Always return valve to
“on” position after
refueling machine.
Fuel Filter
The Polaris ATV is equipped with an in-line fuel filter.
This filter should be replaced by your dealer after every 100 hours of
operation or annually. Do not attempt to clean the fuel filter.
1
ON
OFF
RES
