Polycom CX700 User Manual

User Guide for the Polycom CX700 IP Phone
2 - 2
• High contrast setting
• Text telephone (TTY) setting
• Your PIN or fingerprint ID
• User who is currently logged into the phone
• Touch screen’s calibration
You can also view the current phone network settings.
You must be logged in to configure the basic settings on your Polycom CX700
IP phone.
Changing Date and Time Format
The date and time appears on the graphic display of the Polycom CX700 IP
phone. The phone obtains the date and time automatically from a configured
SNTP server. If the phone cannot obtain the date and time, the display will
flash. Contact your system administrator if either the date or time is incorrect.
You have control over the format of the date and time display. The default date
and time format appears below.
To configure the time and date:
1 Press the Settings soft key.

Polycom CX700 Specifications

Power

power over Ethernet	IEEE 802.3af Class 2
maximum power consumption	13 Watts

LCD Display

display size	5.7 inches
display type	amorphous-TFT Active-Matrix Transmissive
display resolution	320x240

Audio

frequency response	30 – 20kHz
signal-to-noise ratio	78 dB (@ 1kHz)
dynamic range	>80 dB (@ 1kHz)
total harmonic distortion + noise	<0.08% (@ 1 kHz)

Operating Environment

operating temperature range	-10°C to 40°C
relative humidity	80% max (non-condensing)
operating altitude range	-304.8 meter to 3962.4 meter

Weight and Dimensions

dimensions when not tilted	252.7 x 268.6 x 91.3 mm
dimensions when tilted up	193.2 x 268.6 x 192.1 mm
unit weight	2.1 kg
handset weight	200 g
shipping weight	2 kgs
