Troubleshooting 25
Section 6: Troubleshooting
A. SOLVING REGISTRATION PROBLEMS
Image is Vertically Offset
When printing on media other than continuous, the PX450e
decides where to start printing by detecting the start of a die-
cut label, detecting a black mark on the back or detecting a
thru-hole that corresponds to the start of the label.
The following items can cause the media sensor to improperly
detect the start of a label:
1. TOF Offset. TOF stands for Top of Form and this setting
allows you to fine tune the alignment of your printing on
your paper stock. This will be factory calibrated. If fine
tuning is needed, increase this setting to move the image
down on the media; decrease this setting to move the
image up on the media. The unit of measure is 0.1mm.
To access go to Start - Control Panel - Printers and Faxes -
Right click Color Label 450 - Choose Printing Preferences -
Select Offsets. See image in the dialog below for a
graphical example.
