Page 16
P068 Measure Percentage
This parameter determines where the blue distance marker line intersects the echo
profile. Factory set to 80% of the total height of the leading edge echo.
This determines the measured distance.
Values Min = 0
Max = 100
Blue line
positioned 80%
up the leading
edge of the echo
