Quectel BG95 User Manual

LPWA Module Series
BG95&BG96 Compatible Design
BG95&BG96_Compatible_Design 10 / 47
LTE) under LTE Cat M1 and CS voice under GSM. The voice function of BG95 is under
development.
3.
3)
LTE Cat NB2 is backward compatible with LTE Cat NB1.
4.
4)
BG95-MF are under planning. Details of them are currently not included and will be added in a
future release of this document.
5.
5)
LTE B25 is supported on BG96 with R1.2 hardware version.
6. “*” means under development.
2.2. Features Overview
The following table compares general features of BG95 and BG96 modules.
Table 3: Features Overview
Feature
BG96
BG95
Power Supply
3.3V to 4.3V
Typ. 3.8V
BG95-M1/-M2/-N1:
2.6V
1)
to 4.8V, Typ. 3.3V
BG95-M3/-M5:
3.3V~4.3V, Typ. 3.8V
BG95-M4:
Typ. 3.8V
Peak Current
VBAT_BB:
Max 0.8 A
VBAT_RF:
Max 1.8 A
TBD
PSM Current
Typ. 10 μA
Typ. 3.9 μA
Sleep Current
0.8 mA @ Rock Bottom
2)
LTE Cat M1:
1.5 mA @ DRX=1.28s
1.2 mA @ e-I-DRX=40.96s
LTE Cat NB1:
1.96 mA @ DRX=1.28s
1.1 mA @ e-I-DRX=40.96s
2G: 2.0 mA
0.7 mA @ Rock Bottom
2)
LTE Cat M1:
1.65 mA @ DRX=1.28s
0.85 mA @ e-I-DRX=81.92s
LTE Cat NB1:
1.56 mA @ DRX=1.28s
0.81 mA @ e-I-DRX=81.92s
2G: 2.0 mA
LTE-FDD
Supported
Supported
LTE-TDD
Supported (B39)
Not supported
EDGE
Multi-slot class 33
Multi-slot class 33
