Quectel BG95 User Manual

LPWA Module Series
BG95&BG96 Compatible Design
BG95&BG96_Compatible_Design 42 / 47
Table 8: Recommended Thermal Profile Parameters
6.2. Packaging
BG95 and BG96 are packaged in a vacuum-sealed bag which is ESD protected. The bag should not be
opened until the devices are ready to be soldered onto the application. The following figures show the
packaging details, measured in millimeter (mm).
 BG96
The reel is 330mm in diameter and each reel contains 250 modules.
Factor
Recommendation
Soak Zone
Max slope
1 to 3°C/sec
Soak time (between A and B: 150°C and 200°C)
60 to 120 sec
Reflow Zone
Max slope
2 to 3°C/sec
Reflow time (D: over 220°C)
40 to 60 sec
Max temperature
238°C ~ 245°C
Cooling down slope
1 to 4°C/sec
Reflow Cycle
Max reflow cycle
1
