5.Useyourngerstopullthecardclearofthecard
slot,usingtheedgeofthecard.
6.Topreventtheingressofwaterandconsequent
damage,closethecardreaderdoor.
Note:Youcanalsopoweroffthemultifunction
displayandfollowsteps4to7above.
8.3a9xanda12x
Insertingamemorycardorchartcard
1.Openthecardreaderdoor.
2.Insertthecard,asshowninthediagrambelow.
Forslot1,thecardcontactsshouldbefacing
DOWN.Forslot2,thecardcontactsshould
befacingUP .DoNOTforcethecard.Ifthe
carddoesnotteasilyintotheslot,checkthe
orientation.
1 2
D13070-1
3.Gentlypressthecardallthewayintothecard
slot,asshowninthediagrambelow.Thecardis
securewhenanaudibleclickisheard.
1 2
D13071-1
4.Topreventtheingressofwaterandconsequent
damage,closethecardreaderdoor.
Removingamemorycardorchartcard
Fromthehomescreen:
1.SelectMyData.
2.SelectEjectCard.
Amessageisdisplayedpromptingyoutoselect
thememorydeviceyouwanttoeject.
3.SelectSD1foramemorycardinthetopcardslot,
orSD2foramemorycardinthebottomcardslot.
4.Openthecardreaderdoor.
5.Pushtheedgeofthecardtowardstheunit,until
anaudibleclickisheard.
Thecardisreleasedfromthecardslot
mechanism,asshowninthefollowingdiagram:
1 2
D13072-1
Managingdisplaydata
121

Raymarine a78 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Touchscreen	Yes
GPS	Yes
Chartplotter	Yes
Sonar	Yes
Wi-Fi	Yes
Bluetooth	Yes
Ethernet	Yes
NMEA	Yes
Video Input	Yes
Waterproof Rating	IPX6 and IPX7
Radar Compatibility	Yes
NMEA 2000 Compatibility	Yes
Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 70°C
Cartography	Raymarine LightHouse
Weight	1.32 kg (2.91 lbs)
