Raymarine a78 User Manual

4.13Fusionlinkconnection
YoucanconnectaFusion700seriesmarine
entertainmentsystemtoyourmultifunctiondisplay.
Directconnection
1
2
3 4
D12741-1
1.Multifunctiondisplay.
2.Fusionsystem.
3.RayNettoSeaTalk
hs
cable.
4.Fusionethernetconnector.
Directconnectionwithnetworkedmultifunction
displays
3 2
D12742-1
4
1
5
1.Fusionsystem.
2.Fusionethernetconnector.
3.RayNettoSeaTalk
hs
cable.
4.Directlyconnectedmultifunctiondisplay.
5.Networkedmultifunctiondisplays.
Note:TheFusionentertainmentsystemcanbe
controlledbyadirectlyconnectedmultifunction
displayorbyanetworkedmultifunctiondisplay.
Networkconnection
D12740-1
6
5
1
2
6
3 4
1.Networkswitch.
2.Fusionsystem.
3.RayNettoSeaTalk
hs
cable.
4.Fusionethernetconnector.
5.SecondFusionsystem(themultifunction
displaycanbeconnectedtomultipleFusion
entertainmentsystems).
6.Networkedmultifunctiondisplays.
Note:TheFusionentertainmentsystemcan
becontrolledbyanycompatiblenetworked
multifunctiondisplaywhenconnectedusinga
networkswitch.
66aSeries/cSeries/eSeries

Raymarine a78 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Touchscreen	Yes
GPS	Yes
Chartplotter	Yes
Sonar	Yes
Wi-Fi	Yes
Bluetooth	Yes
Ethernet	Yes
NMEA	Yes
Video Input	Yes
Waterproof Rating	IPX6 and IPX7
Radar Compatibility	Yes
NMEA 2000 Compatibility	Yes
Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 70°C
Cartography	Raymarine LightHouse
Weight	1.32 kg (2.91 lbs)
