4.23Camera/Videoconnection
Acameraoravideodevicecanbeconnecteddirectly
toNewcSeriesandNeweSeriesmultifunction
displaysusingthevideoconnectoronthepowerand
datacable.
Note:Videodevicescannotbedirectlyconnected
toNewaSeriesmultifunctiondisplays.Forcamera
connectionstoaNewaSeriesdisplaypleaserefer
totheIPcameraconnectionsection.
Examplesofvideosourcesthatyoucanconnectto
thedisplayinclude:
•Videocamera.
•Thermalcamera.
•DVDplayer.
•Portabledigitalvideoplayer.
D12178-2
1
2
4
3
1.Rearconnectorpanelofmultifunctiondisplay.
2.Poweranddatacable.
3.BNCvideoconnector(input1).
4.Videosource—forexample,videocamera.
Note:Tolistentoamovie’saudiotrack,any
connectedDVDordigitalvideoplayerwillrequire
speakerstobeconnectedtotheplayersaudio
output.
4.24Camera/videoin-outconnection
Acamera/videodeviceorexternaldisplaycanbe
connectedtoNeweSeriesmultifunctiondisplays
(excludingthee7/e7D)usingthededicatedvideo
in/outconnector.
Note:NewaSeriesandNewcSeriesmultifunction
displaysdonothaveadedicatedvideoin/out
connector.
VideoIn
Examplesofvideoinputsourcesthatyoucan
connecttothedisplayinclude:
•Videocamera.
•Thermalcamera.
•DVDplayer.
•Portabledigitalvideoplayer.
D12328-1
1
2
4
3
1.Rearconnectorpanelofmultifunctiondisplay.
2.Videoaccessorycable.
3.BNCvideoconnector(input2).
4.Thermalcamera.
Note:Tolistentoamovie’saudiotrack,any
connectedDVDordigitalvideoplayerwillrequire
speakerstobeconnectedtotheplayersaudio
output.
Videoout
Examplesofvideooutputdevicesthatyoucan
connecttothedisplayinclude:
•HDTVwithVGAinput.
•VGAmonitor.
D12329-1
1
2
4
3
1.Rearconnectorpanelofmultifunctiondisplay.
2.Videoaccessorycable.
3.VGAcabletoexternaldisplay.
Cablesandconnections73
