IconDescription

Scenepresetmodefornightdocking.

Scenepresetmodeforidentifying

peopleorobjectsinthewater.

Rear-viewmode—imageisipped

horizontally.

Zoomsetting:2xzoom.

Zoomsetting:4xzoom.

Singleactivecontrolleronnetwork.

Multipleactivecontrollersonnetwork.

PC/laptopdetectedonnetwork.

Pointmodeenabled.

Pointmodedisabled.

StabilizationOff.

StabilizationOn.

FFC(FlatFieldCorrection)

PeriodicallythecamerawillperformaFlatField

Correction(FFC).Thiswillnetunethethermal

imagetosuitthecurrentambienttemperature.

TheFFCoperationisindicatedbyamomentary

pauseandagreenrectangledisplayedintheupper

leftofthethermalvideoimage.

23.3Controlsoverview

Thethermalcameraapplicationisavailableon

compatibleRaymarinemultifunctiondisplaysand

systems.Itincludescontrolsforthethermalcamera.

Rotarycontrol

Zoomimagein/out.

Joystick•Panandtiltcamera

Note:Ontouchscreen

displaysyoucanalsousethe

touchscreentopanandtiltthe

camera.

•Navigatemenus

OKConrmmenuselection

CANCEL/BackCancelselection

RANGEIN/OUTZoomimagein/out.

Thermalcameraapplication—Panandtiltcameras
