3.UsetheRangeinorRangeoutcontrolsto
switchtheactiveapplicationbetweensplitscreen
andfullscreenviews.
Selectingtheactivewindow—e7/e7D
Whenviewingasplitscreenpageyoucanselectthe
activeapplicationandviewitfullscreenonane7/
e7Dwiththetouchlockenabledbyfollowingthe
stepsbelow.
Withapagefeaturingmultipleapplicationsdisplayed:
1.PresstheMenubutton.
2.SelectCycleapplication.
Selectingcycleapplicationcyclesthroughthe
availableapplications.
3.SelectFullscreentoviewtheactiveapplication
infullscreen,or
4.SelectSplitscreentoreturntothesplitscreen
view.
Switchingtheactivepaneordisplayusing
thekeypad
TheSwitchActivebuttonisusedtoswitchtheactive
paneonamultiapplicationpageand/ortoswitch
theactivedisplay.
Withmultipledisplaysconnectedand/ormultiple
applicationpage(s)displayed:
Cyclesequence
D12880-1
2 3
4
1
5
1.PresstheSwitchActivebuttontoenterswitch
mode.
2.UsetheRotarycontroltocyclethroughthe
availablepanesand/ordisplays.
Thekeypadwillcyclethroughdisplaysinthe
orderinwhichtheywerepaired.Onmulti
applicationpagestheRangebuttonscanbeused
toswitchtheactiveapplicationbetweenfulland
splitscreen.
3.PresstheBackbuttonortheSwitchActive
buttontoexitswitchmode.
6.10Screenoverview
D12196-2
7
6
1
2 3
4
5
ScreenitemDescription
1Home
•Displayswithatouchscreen—Select
theonscreenHomeicontoaccessthe
Homescreen.
•Non-touchscreenandHybridTouch
displays—UsethephysicalHomebutton
toaccesstheHomescreen.
2
Databar—providesinformationaboutyour
vesselanditsenvironment.Thetypeof
informationinthedatabarcanbecustomized
fromtheHomescreen>Customize>
DatabarSet-upmenu,ifrequired.
3
Menu—menuoptionsarespecictothe
applicationthatyouarecurrentlyusing.
4
Statusbar—providesinformationspecic
toeachapplication.Thisinformationcannot
beeditedormoved.
5
Contextmenu—providesinformationand
optionsspecictoeachapplication.
6Menuoptions—menuoptionsaredisplayed
whentheMenuisselected.
7
Pop-upmessages—alertyoutoasituation
(suchasanalarm),orunavailablefunction.
Pop-upmessagesmayrequirearesponse
fromyou—forexample,selectOKtosilence
alarms.
Menus
Menusenableyouconguresettingsand
preferences.
Menusareusedinthe:
•Homescreen—tocongureyourmultifunction
displayandexternally-connectedequipment.
•Applications—tocongurethesettingsforthat
particularapplication.
Gettingstarted
97

Raymarine a78 Specifications

General

Display Size	7 inches
Display Resolution	800 x 480 pixels
Touchscreen	Yes
GPS	Yes
Chartplotter	Yes
Sonar	Yes
Wi-Fi	Yes
Bluetooth	Yes
Ethernet	Yes
NMEA	Yes
Video Input	Yes
Waterproof Rating	IPX6 and IPX7
Radar Compatibility	Yes
NMEA 2000 Compatibility	Yes
Operating Temperature	-15°C to 55°C
Storage Temperature	-20°C to 70°C
Cartography	Raymarine LightHouse
Weight	1.32 kg (2.91 lbs)
