110 ST6001+ Autopilot Control Unit - Owner’s Handbook
Appendix
Dealer Calibration: possible settings with Type 100/300
Calibration setting Vessel type
Displacement Semi Displacement Planing Stern drive (I/O) Your settings
Vessel type DISPLACE SEMIDISP PLANING STERNDRV
Calibration lock OFF OFF OFF OFF
Rudder gain 5543
Counter rudder 7775
Rudder alignment 0000
Rudder limit 30 30 30 20
Turn rate limit 20 15 15 8
Cruise speed 6 8 15 15
Off course angle 20202020
AutoTrim 2333
Power steer OFF OFF OFF OFF
Drive type 3443
Rudder damping 2222
Variation OFF OFF OFF OFF
AutoAdapt NORTH NORTH NORTH NORTH
Latitude 0000
Wind Trim
(displacement only)
1 --- --- ---
AutoTack angle
(displacement only)
100 --- --- ---
AutoRelease
(stern drives only)
--- --- --- ON
Response 1111
Note: Information applies to Type 100/300 Course Computers with Version 15 software.
