ypicalsystems
Examplesoftypicalsystems.
Note:
P
owersupplyconnectionsarenotshowninthefollowingexample.For
detailsonhowtoconnectpowertoyourdevices,refertothepower
connectiondetailsintheapplicabledeviceinstructions.
Examplebasicsystem
1.R aymarinethermalcamera(M300illustrated).
2.Raymarinenetworkswitch(RNS-5illustrated).
3.Raymarineradarscanner(Cyclone™illustrated).
4.SeaTalkng®instrument(i70sillustrated).
5.ExternalGNSSantenna(e.g.:GA200,partnumberA80589).
6.ExampleRaymarineCHIRPsonartransducer,compatiblewiththeAxiom
2ProSvariant(CPT-Sillustrated,connectedviaA80490adaptorcable).
7.Axiom®2Prodisplay.
8.SeaTalkng®5-wayblock(terminatedSeaTalkng®CANbusnetwork).
9.ExampleRaymarineRealVision™Maxsonartransducer,compatiblewith
theAxiom2ProRVMvariant(RVM-100illustrated).
Note:
P
owersupplyconnectionsarenotshowninthefollowingexample.For
detailsonhowtoconnectpowertoyourdevices,refertothepower
connectiondetailsintheapplicabledeviceinstructions.
Exampleexpandedsystem
1.Raymarinethermalcamera(M300illustrated).
2.Y achtSense™LinkMarineRouter.
3.Y achtSense™DigitalControlSystem(Mastermoduleassemblyillustrated).
4.Raymarineradarscanner(Cyclone™illustrated).
5.ExternalGNSSantenna(e.g.:GA200,partnumberA80589).
6.ExampleRaymarineCHIRPsonartransducer,compatiblewiththeAxiom
2ProSvariant(CPT-Sillustrated,connectedviaA80490adaptorcable).
7.Axiom®2Prodisplay.
