Specification
T
ransducerconnections
(RVMvariants):
•25-pinRV/RVMconnector.
•11-pin1kWconnector.
T
ransducerconnections(S
variants):
25-pinRV/RVMconnector(requires
adaptorcableforCPT-Sonlytransducers.
21.
7RVMvariantsonarspecification
Sonarchannels
Y ourproductsupportsthefollowingsonarchannels:
RV/RVMtransducerconnection
CHIRPsonarchannels
3DVision(R ealVision™)
DownVision™
Side Vision™HighCHIRP
Sonar(CPT-Stransducer)
1k Wtransducerconnection
CHIRP/traditionalsonarchannels
HighCHIRPMediumCHIRP
L owCHIRPLowfrequency
ConicalsonarMediumfrequency
Highfrequency
Sonarrange
Thesonarrangeistheeffectivedepthordistancethatthetransducercan
operateto
,inoptimumweatherconditions.
ThefollowingrangesapplytoRealVision™Max3Dsonarchannels:
Note:
Thelistedsonarchannelrangesareindicativeonly
,andaresubjectto
changedependingupontheconnectedtransducer.
Sonarchannel
R
ange
CHIRPsonar:
0
.6m(2ft)to366m(1,200ft)
Down
Vision™:
0.6m(2ft)to183m(600ft)
SideVision™:
0.6m(2ft)to91m(300ft)
RealVision™Max3D:
0.6M(2ft)to91m(300ft)
Traditionalsonarrange
ThefollowingrangesapplytoTraditionalsonarchannels:
Sonarchannel
Range
Traditionalsonar:
0.9m(3ft)to1,524m(5,000ft)(in
optimumconditions,usinga1kW
transducer)
21.8Svariantsonarspecification
Thesonarrangeistheeffectivedepthordistancethatthetransducercan
operateto,inoptimumweatherconditions.
CHIRPsonarchannel
Range
100WSonar(conicalbeam):
0.6m(2ft)to274m(900ft),
dependingonwaterconditions
21.9Conformance/approvals
Thisproductiscompliantorapprovedtothefollowingstandardsorbythe
listedentities.
•RadioEquipmentDirective2014/53/EU
•EN60945:2002(Europe,AustraliaNewZealand)
Axiom2Pro9technicalspecification
95
