Raymarine AXIOM+ Series User Manual

–R
V-320Sstarboardtransducer(A80474)
4
•R
V-400RealVision™3Dstainlesssteel0°thru-hullall-in-onetransducer(A80615)
•RV-412PandRV-412SRealVision™3Dstainlesssteel12°thru-hullsplit-pairtransducers
(T70450)
–RV-412Pporttransducer(A80616)
–RV-412Sstarboardtransducer(A80617)
•RV-420PandRV-420SRealVision™3Dstainlesssteel20°thru-hullsplit-pair
transducer(T70451)
–RV-420Pporttransducer(A80618)
–RV-420Sstarboardtransducer(A80619)
Down Vision™transducers
TheDownVision™transducersshownbelowcanbeconnectedusingadaptorcableA80490.
1
CPT-100D VSplastictransommounttransducer(A80351)(replacesCPT-100A80270)
2
CPT-110plasticthru-hulltransducer(A 80277)
3
CPT-120bronzethru-hulltransducer(A 80271)
CHIRPconicalbeamtransducers(usingDown Vision™typeconnector)
ThetransducersshownbelowcanbeconnectedusingadaptorcableA80490.
CPT-StransducersuseCHIRPsonartechnologytoproduceaconical-shapedsonarbeam.
Note:CPT-StransducersdoNO TofferDownVision™orRealVision™channels.
Documentandproductinformation
17
