2.Ensurethatthedevicebeingconnectedhasbeeninstalledinaccordancewiththeinstallation
instructionssuppliedwiththatdevice
.
3.Ensuringcorrectorientation,pushcableconnectorsfullyontothecorrespondingconnectors.
4.Engageanylockingmechanismtoensureasecureconnection(e.g.:turnlockingcollars
clockwiseuntiltight,orinthelockedposition).
5.Ensureanybareendedwireconnectionsaresuitablyinsulatedtopreventshortingandcorrosion
duetowateringress.
4.2Powerconnection
Thepowercablemustbeconnectedtoa12Vdcpowersupply,thiscanbeachievedbyconnecting
directlytoabattery,orviathedistributionpanel.For24Vvesselsasuitablevoltageconverteris
required.Theproductisprotectedagainstreversepolarity.
1.P ower/NMEA2000cableconnectstotherearofthedisplay.
2.GroundwireconnectstoRFgroundpoint,ifnogroundpointisavailableconnecttothebattery
negative(-)terminal.
3.Positive(Red)wireconnectstobatterypositive(+)terminal.
4.Waterprooffuseholderwith7Afusemustbefitted(notsupplied)
5.Negativewireconnectstobatterynegative(-)terminal.
In-linefuseandthermalbreakerratings
Thefollowingin-linefuseandthermalbreakerratingsapplytoyourproduct:
In-linefuseratingThermalbreak errating
7A7A
Note:
•Thesuitablefuseratingforthethermalbreak erisdependentonthenumberofdevicesyouare
connecting.IfindoubtconsultanauthorizedRaymarinedealer.
•Y ourproduct’spowercablemayhaveanin-linefusefitted,ifnotthenyoumustaddanin-line
fuse/breakertothepositivewireofyourproduct’spowerconnection.
Caution:Powersupplyprotection
Wheninstallingthisproductensurethepowersourceisadequatelyprotectedby
meansofasuitably-ratedfuseorthermalcircuitbreaker.
Connections39
